Solutions Of The Stifling Heat In The Top Floor By Chimney Effect
Taiwan is located in the subtropics area. Therefore the top floor of the building is usually hot and unpleasant for people in the summer. The case was on the top floor of a regional post office building. The electricity bill was exceptionally high, especially in the summertime. Therefore the building was designed with an attic with a series of automatic windows for improving the natural vent. The stifling heat will be out of the building from the windows. Meanwhile, the air circulation of the indoor space will be enhanced and cost down the electricity bill.
The Advantage Of Jalousie Type Of Windows
Each side of the opening of the attic has installed a row of jalousie windows. People can adjust the opening angle of leaves according to the season. If the leaves were fully opened, the vent area would be the largest in the summertime. When it comes to winter, people could make the windows slightly opened to keep the interior warm and ventilation. Furthermore, the jalousie windows also with solar shading features. Changing the opening angle according to the angle of the sun during the daylight.
Operate The Windows By Automatic Window Opener System
With the help of #automaticwindowopeners , people could easily adjust from the wall switch or remote controller instead of camping on the ladders and open the windows one by one.
The System Was Based On KST-A01 Linear Actuators
We installed #linearactuators on the window frame. It will be easier for maintenance. For standard jalousie windows, we use KST-A01 Linear Actuators with about 50mm stroke length. The mechanism could open the leaves to about 90 degrees. In addition, our control box, KST-B1 Series Controllers, is made especially for the #smokevent system, opening a row of windows simultaneously and providing ports for connecting with the fire system. The motor inside the KST-A01 Linear Actuators was made in Taiwan. The motor works with precision-machined metal gear. Therefore, the lifespan is longer than other same rank linear actuators. KST-A01 Linear Actuators are protected by Limit Switches at both ends. Every actuator will be working in the same length. The feature is very crucial for opening a lot of windows at the same time.
Cases Of Attic Vent With Automatic Window Opening Systems
Case: Attic Vent In A Factory
Case: Attic Vent In A Spring Park
Case: Vent System On The Roof Ridge Of A Factory
Case: Vent System On The Roof Ridge Of A Factory
Basic information about the case of Automatic Windows in a post office building
Located: Taichung, Taiwan
Year of installation: 2020
Application of linear actuator: natural ventilation, smoke ventilation, High windows
Type of window actuator: KST-A01 Linear Actuator, KST-B1 Window Controls
Type of window: Jalousie Windows
